Features: • 400 × 300 uncooled VOx thermal sensor technology • Athermalized lens (thermal), focus-free • Support body temperature measurement • Measurement Accuracy: ±0.3°C, with blackbody • Active deterrence with white light & siren • Various lens optional 7.5 mm) • 2/2 alarm in/out • Micro SD memory, IP67, PoE,ePoE Technical Specifications: Thermal • Detector Type Vanadium oxide uncooled focal plane detector • Effective Pixels 400 × 300 • Pixel Pitch 17 µm • Spectral Range 8 µm–14 µm • Thermal Sensitivity (NETD) =40 mK • Focal Length 7.5 mm • Field of View 7.5 mm: horizontal: 53.7°, vertical: 39.7° • Focus Mode Fixed-focal • Aperture F1.0 • Digital Detail Enhancement (DDE) Yes • Thermal Image Stabilization Electronic Image Stabilization • AGC Auto; manual • Noise Reduction 2D NR; 3D NR • Image Flip 90°/180°/mirror • Color Palettes 18 color modes selectable such as Whitehot/Blackhot/Ironrow/Icefire. Temperature • Measurement Range 30°C ~+45°C • Temperature Accuracy Max ±0.3°C with blackbody Max ±1°C without blackbody • Temperature Mode Spot: 12 Line: 12 Area: 12 Support 12 rules simultaneously Visible Lens • Focal Length 4mm • Max Aperture F2.0 • Angle of View H: 84° V: 45° Audio and Video • Video Compression H.265; H.264; H.264H; H.264B; MJPEG Resolution • Main stream: (1280 × 1024/1280 × 960/1280 × 720/400 × 300), 1280 × 960 by default; Sub stream: (640 × 512/640 × 480/400 × 300@), 400 × 300 by default • Audio Compression G.711a; G.711mu; AAC; PCM • Image Encoding Format JPEG General Function • Two-way Talk Yes Network Protocol • HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP;SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP • Region of Interest (ROI) Yes • Edge Storage FTP; Micro SD card (256G, hot plug) • Interoperability ONVIF; CGI; Dahua SDK • Browser: IE: IE8 and the later, and explorer with IE core Google: 42 and the earlier Firefox: 42 and the earlier Safari: 10 and the earlier • User/Host 20 channels at most (the total bandwidth 64M) Security • Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access User Management • Support 20 users at most and users are classified as two groups-administrator group and user group. • Malfunction Detection • Network disconnection; IP addresses conflict; SD card error (status or storage space) Port • Analog Video Output 1 channel of CVBS output with BNC port • Network 1 10M/100M Ethernet port (RJ-45) • Alarm Input 2 channels • Alarm Output 2 channels • Audio Input 1 channel • Audio Output 1 channel • Alarm Linkage SD card recording/on-off output/siren and light/email/PTZ/snapshot Alarm Event • Motion detection/privacy mask/audio detection/SD card abnormality/network abnormality/anti-burn warning • RS-485 1 channel Power • Power Supply 12V±20% DC, 1.2A, PoE (802.3af), ePoE • Power Consumption Basic: 5.0W • Maximum: 12W (power adapter excluded) Environment • Operating Temperature 10°C to +30°C • Operating Humidity =95% • Self-Adaptive Auto heating to protect the chip under the cold environment Physical Characteristics • Protection Grade: IP67, anti-surge 6KV, anti-elctrostatic 8KV (touched by objects), anti-elctrostatic 15KV (air) • Packaging Dimensions 365 mm × 175 mm × 176 mm (14.37" × 6.89" × 6.93") • Net Weight =1.4 kg (3.09 lb) • Gross Weight =1.9 kg (4.19 lb) • Power Adaptor Selectable • Lens Contained Certification • Certifications CE; FCC
